序号Number
|
技术参数Specifications
|
单位Unit
|
型号model
|
|||||
YW27—100
|
YW27—200
|
YW27-315
|
YW27-500
|
YW27-1250
|
||||
1
|
公称力Rated pressure
|
KN
|
1000
|
2000
|
3150
|
5000
|
1250
|
|
2
|
液压垫力Cushion force
|
KN
|
400
|
600
|
800
|
1600
|
4000
|
|
3
|
液体最大工作压力边力Max workong hydraulic pressure
|
Mpa
|
25
|
25
|
25
|
25
|
25
|
|
4
|
滑块行程Slide stravel
|
mm
|
600
|
700
|
800
|
900
|
900
|
|
5
|
液压垫行程Cushion stroke
|
mm
|
200
|
260
|
300
|
300
|
300
|
|
6
|
滑块下平面至工作台面最大距离Destance between down-flat of slide and WorktabIe
|
mm
|
800
|
1100
|
1250
|
1500
|
1500
|
|
7
|
滑块行程速度
Speed of slide |
空载下行Empty descending
|
mm/s
|
120
|
100
|
80
|
120
|
80
|
工作Pressing
|
mm/s
|
20
|
12
|
8
|
10
|
6--10
|
||
回程return
|
mm/s
|
60
|
52
|
42
|
40
|
45
|
||
8
|
工作台有效尺寸Effective area of table
|
左右L-R
|
mm
|
570
|
900
|
1200
|
1400
|
2400
|
前后F-B
|
mm
|
600
|
900
|
1200
|
1400
|
1600
|
||
9
|
液压垫尺寸Overall dimensions of machine
|
左右L-R
|
mm
|
450
|
700
|
1000
|
1100
|
1800
|
前后F-B
|
mm
|
400
|
600
|
800
|
100
|
1000
|
||
10
|
电机总功率Motor power
|
KW
|
7.5
|
15
|
22
|
44
|
60
|
|
11
|
重量Weight
|
KG
|
5000
|
13200
|
1820
|
32000
|
75000
|
